Quarter Turn Lock

1401

Cam 90° Index
19
Lock cylinder

45 Lock

Rubber seal 20.1+00.1
5.2
GH=20 Ø22.5 +00.5
H Panel cutout
6 with non-stoper cam
8

Zinc die handle and housing black powder coated or bright chrome; m.s. zinc plated cam. Accessories ref. to page #
1. CAM ref. to page 9A-001
Black Textured Powder Coated 1401-20-20 1401-20-20B Remark
Bright Chrome 1401-20-30 1401-20-30B 1. Key different on request.
2. CH751 key code on request

Ø28 Ø22.5+00.5
H 12.7
GH=18

Ts=1.5-8
20.1+00.1

Panel cutout

19 L
90°
SW13
1401-30-316L Accessories ref. to page #
SUS316L housing, insert,sus304 cam 1. CAM ref. to page 9A-001
316L SUS316L
