Swinghandle Lock
1201

Index 36 GH=20 Rubber sealing or
EPDM foam sealing

Lock 30
120
110

9.1 25+00.5
25 Ts=1-3
Panel Cutout
Black PA or zinc die lock housing, zinc die handle black powder
coated,zinc die shaft and m.s. zinc plated fixing parts. PA
1201-02-0320
Small size Zinc die handle,PA housing Zinc Die
1201-02-0120 1201-02-0220

36 GH=18 18

90°160
100 30

8
150
50+00.5 50 50+00.5

23 21 25 25+00.5
Panel Cutout

Accessories ref. to page # Black PA body, zinc die, shaft and m.s. zinc plated fixing parts.
1. CAM ref. to page 9A-001
Remark Code mode PA handle and housing
1. Key different on request. 1201-01-0320
2. CH751 key code on request

1B-002
