Pocket Pull
3305, 3307

Index AA

Handles 123 114.5+00.2 <1>
91.4 <2>
B
B
121.4

46.7

PANEL 64.3 A-A 38+00.2
THICKNESS Panel cutout

3.6
(SEE TABLE)
25.4
2.5 23 22.7
B-B
Black ABC

1.0-1.8 3305-01
1.8~3.3 3305-02
3.3~4.8 3305-03
4.8~6.3 3305-04

Customer special logo can be here.
Logo size: 50X80
50 26 2
67
42

8
50+00.2

94 Ts 100+00.5
113
3307-01 Panel cutout
Black PA+GF 3307-02
Panel Ts= Min ~Max 3307-03
0.8~1.2
1.2~1.6
1.75~2.2

3C-003
