SPECIALISED INDUSTRIAL

GROOVING TOOLS

Designed to make grooves near pipe ends for mechanical joiners

Product Nime 220 V Pipe Pipe Weight
category Manual thickness
GROOVER 10A/10B 33,7 - 219 mm 107 kg
330600 VICTAULIC VE26S 54 - 155 mm 1,8 - 2,9 mm 10 kg

330601 1,7 - 5,5 mm

MECHANICAL PIPE BENDERS

Manually operated (for stainless steel, copper, brass, aluminium, etc.)

Product Name PIpe outer Ø Wall thickness Weight
category
2,5 kg
921379000000 MINOR-BEND 4 - 18 mm 0,5 - 2 mm 11 kg
23 kg
921380000000 BIG-BEND 10 - 32 mm 0,5 - 2 mm
7 kg
921381000000 SUPER-BEND 16 - 42,2 mm 1 - 2 mm

921414000000 PIENI QUICK ⅜� - ¾� / 6-32 mm 2-4 mm
BEND

ELECTRIC PIPE BENDERS

Compact, lightweight pulse inverter machines for light-duty work on job sites.
Designed for the bending of copper pipes. Former data shown in the table
below.

Product category Name Weight
330201
Formers + back Rems Curvo 40 220V 8 kg (24 kg)

330220 Name Ø+R

Former + back former 32 mm R114 (6, 7)
28 mm R102 (2, 4, 5)
25 mm R98 (4, 6, 7)
22 mm R77 (1, 2, 4)
20 mm R75 (1, 3, 6, 7)
18 mm R70 (1, 2, 4, 5, 7)
15 mm R55 (2, 3, 4)
12 mm R42 (2, 4)

1. Cu-U: Coated copper
2. St 10312: Stainless steel tubes for pressfitting systems EN10217-7
3. St 10305-U: Soft carbon steel tubes for pressfitting systems EN 10305-3
4. St 10305: Soft seamless steel pipe EN 10305-1 / -2 / -3
5. St 10255: Welded steel pipes (threadable) EN 10255
6. St 50086: Electric conduit DIN EN 50086
7. V: Multi-layer composite tubes for pressfitting systems

30
