METAL DETECTORS

Product Name Depth specified by the Weight Further
category C.SCOPE CS440XD manufacturer 1,5 kg information

1712 Paljastaa suuret metallit yli 1m 17 kHz
syvyydestä

Locates larger metal objects from approx. 1 m deep

ABLE PULLERS

Ramirent has the necessary tools and equipment for
pulling underground cables. When considering cable
pulling equipment, attention should be given to the
cable’s tensile strength, the distance being pulled,
terrain, bends, etc. If the distance is long or there are
several bends, adding a cable dog to help push the cable
is recommended. When using more than one machine
at the same time, it is important to run them on the
same current for ensuring synchronisation.

Tepa 515 Product Tepa 500 Pull/push load Speed Weight Note!
category 250 kg
POWER 380V Model Pull + push: 600 kg 15 m/min 200 kg Cable approx. 150 m
COMBUSTION 270200 RK-700S Pull + push: 800 kg 11 m/min 220 kg Cable approx. 150 m
ENGINE 270201 NKH-B200 Pull + push: 800 kg 11 m/min 250 kg Cable approx. 150 m
NKH-B200GS Pull + push: 600 kg 15 m/min 15 kg Cable approx. 150 m
DRILL 270202 RK-700P Incl. drill, frame, 50 m
OPERATED TEPA500 Pull: 500 kg 3-10 m/min 2 kg cable, rope drum
Incl. drill, frame, push-
270203 TEPA515 Push: 300 kg 3-10 m/min ing device and pressing

rollers

CABLE STOCKINGS AND WIRE GRIPS/CABLE CLAMPS

These are used when pulling cables with pulling tools, thus preventing
damage to the cable.

NOT FOR LIFTING.

Product Wire grips/cable clamps Size
category
270406 Cable stockings, length 60 cm 6-35 mm² (Ø 3-8 mm), 12-26 mm² (Ø 4-12 mm),
Cable stockings, side opening 16-70 mm² (Ø 4-12 mm), 50-150 mm²
270407 (Ø 6-18 mm), 1-10 mm², 1-5 mm²
270408 Gufe 16-70 mm² (Ø 5-12 mm)

10-20 mm, 20-30 mm, 30-40 mm, 40-50 mm,
50-65 mm, 65-80 mm, 80-95 mm/60cm,
90-110 mm, 110-130 mm

20-30 mm, 40-50 mm, 65-80 mm, 95-110 mm

21
