SPECIALISED INDUSTRIAL

MACHINE TRANSPORT AND LOGISTIC EQUIPMENT

Used to move heavy equipment, machines or units during installation or maintenance work.

                        HYDRAULIC TOE JACKS

                        The toe allows for lifts to be made with very little clearance.

                        The toe boot offers a floating Slide Shoe feature and lift height can be adjusted,
                        if necessary. It is also possible to lift from the end of the jack.

                        On Jung toe jacks, the pump and jack are compactly built into the same unit. It
                        is also possible to use a separate 500 bar pump.

                        Product   Name     Capacity      Toe height -         Toe    Stroke  Height  Weight
                        category                       mm (min-max/         depth    height
                                  JH6G+                lifting points x    (usable)          245 mm   23 kg
                          230015  JH10G+L                                            140 mm  233 mm   25 kg
                                  JH10G+                    spacing)        59 mm    113 mm  275 mm   29 kg
                                                                            54 mm    150 mm
                                           6 t 12-157 (6 x 29)              54 mm

                                           10 t 15-138 (4 x 41)

                                           10 t 15-180 (5 x 41)

                        RANSPORT TROLLEYS

                        Jung transport trolleys are equiped with floor-friendly JUWA polyurethane
                        composite casters.

                        Trolleys with different load capacities may be used together, provided that the
                        equipment has the same structural height (generally 110 mm).

                        Single transport trolleys with 360-degree turning castors

                        Product            Name          Load              Height       Exterior     Paino
                        category           JLB3K-JUWA  capacity            110 mm    dimensions      37 kg

                             270100                       3 ton                          (L x W)

                                                                                     675 x 435 mm

                        Front end transport trolleys with geared saddle and bar for pulling

                        Product            Name          Load              Height        Exterior    Weight
                        category                       capacity                       dimensions
                                           JL3K                            110 mm                      12 kg
                             270100        JL7K           3 ton            110 mm         (L x W)     36 kg
                                           JL14K          7 ton            110 mm                     64 kg
                             270101                      14 ton                       22 x 280 mm

                                                                                     445 x 590 mm

                                                                                     580 x 1000 mm

12
