OTDR INSTRUMENTS

Product Name Wavelengths Dynamics Weight
category 2,1 kg
2,1 kg
700020 FTB-200 + FTB7300 1310 / 1550 nm 38/34 dB (max. 260 km) 2,1 kg
1310 / 1550 nm 35/34 dB (max. 260 km) 2,1 kg
700020 FTB-200 + FTB7200

700021 FTB-200 + FTB7400 1310 / 1550 / 1625 nm 42/41/41 dB (max. 400 km)

700021 FTB-200 + FTB7500 1310 / 1550 nm 45/45 dB (max. 400 km)

The OTDR unit does not come with a fibre optical microscope, adapters, front or back
measuring fibres

ETHERNET TEST EQUIPMENT

Product Name Information
category

600180 FTB-200 + 8510B:
FTB8510B +Ericsson LG compatible 1000BASE-LX SFP Transceiver, 1310nm, 10KM, Single-
moduuli mode, LC Duplex, 1.25G

600182 FTB200+ 8510B:
600182 FTB8510G+ +Ericsson LG compatible 1000BASE-LX SFP Transceiver, 1310nm, 10KM, Single-
FTB8310B mode, LC Duplex, 1.25G.
8510G:
FTB1+ +Transceiver 10GBASE-LR, 1310nm, 10500Mbps(Tx), 10500Mbps(Rx), 10km, LC
FTB880 Connector, Panel Mount
+10GBASE-ER, Duplex LC connector, and OC-192/STM-64/10G SONET ER LC, 40
Km, 1550 nm XFP transceiver
+ 10 Gigabit Ethernet, and 10G Fibre Channel. PicoLight PL-XXL-SC-S45-22
transceiver has a maximum reach of 400m at 10.3125 Gb/s data rate. This prod-
uct features an 850nm VCSEL Laser, duplex LC connector.

EXFO-TK-FTB-880-FLEX-10GIGE/F1 Modular Test Kit
10GigE SONET SDH PDH/1G-Elec & Optical 1GigE/FCALL-Fiber Channel
1,2,4,8,10/
STM1-155Mbit/s Optical Rate/STM16-2488Mbit/s Optical Rate/STM4-622Mbit/s
Optical Rate/STM64-10Gbit/s Optical Rate

FIBRE INSPECTION PROBES

Product Name Image Mount Pass/fail Further informa-
category transm function tion

700080 EXFO FIP-400 Analog 8-pin mini-DIN no Equipped with a
separate display. Fibre
700082 FBP-HD1/FIP-S Analog 8-pin mini-DIN no inspection probe only.

Fibre inspection probe
only. Equipped with a
built-in display.

700086 EXFO FIP-410B Digital USB no Equipped with a sepa-
rate display.
